Challenger SRM10 Short Rise Car Lift 10,000 lbs - New Black Color

This Item has a 30-Business Day Lead-Time
List Price: $7,827.21
$
You save $!
This product qualifies for FREE SHIPPING!
Product Code: SRM10
Choose your options:
Delivery Options
Please select a Delivery Option(required):
Delivery Notice
24 Hour Delivery Notice(required):
Optional Challenger Accessories
#63100(optional):
#10356(optional):
#10354(optional):
#SR10-001(optional):
Challenger Lift SRM10 Short Rise Car Lift
ALI Certified

download manual

To view the lift inspection guide Click Here

Challenger’s shortrise lift is a great choice for brake and tire servicing needs. Dual hydraulic cylinders provide a 10,000 lb. capacity to lift vehicles ranging from small passenger cars to light trucks. Standard spotting blocks and optional auxiliary adapters reach an even wider range of vehicle lift points.

Standard 2 position spotting blocks and auxiliary adapters reach a wide range of vehicle pick up points. Lug nuts and other small parts are always within reach with the SRM10’s inset storage trays. Its small footprint compared to other lift models make the SRM10 a perfect fit.

  • 10,000 lb. lift capacity
  • 22” raised height
  • Standard two-position spotting blocks reach pickup points on a wider range of vehicles
  • Three locking positions for ease of use
  • Powder coat finish provides long-lasting durability
  • Can be mounted flush

Black Only. Red & Blue are Now Discontinued

Specifications
SRM10
Lift Capacity10,000 lbs. (4536kg)
A Rise Height22" (559mm)
Lowered Height4-1/4" (108mm)
Locking Bar Heights13-13/16", 18-3/8", 21-1/4" (351mm, 467mm, 540mm)
B Low Adapter Position4-3/4" (121mm)
C High Adapter Position6-3/4" (171mm)
D Overall Width85" (2159mm)
E Outside Width of Platforms72" (1829mm)
F Width between Platforms23" (584mm)
G Platform Overall Length50" (1270mm)
H Ramp & Platform Overall Length82-1/2" (2096mm)
I Overall Length92-7/8" (2359mm)
Rearward Movement13-1/4" (337mm)
Motor / Voltage1HP, Single Phase, 60Hz / 115V

To view or download the Service Bay Layout click here


Challenger SRM10 specs drawing

LIMITED WARRANTY

Challenger Lifts, Inc. (CLI) lifts are guaranteed to the original owner. CLI shall repair or replace, at CLI option, for the full warranty period those parts that prove upon inspection to be defective and pay for reasonable costs of transportation and/or labor for replacement of said parts for the warranty period stated below. This warranty shall not apply unless the product is installed, used and maintained according to CLI’s specifications set forth in CLI’s installation, operation, and maintenance instructions. Use of any unapproved parts or accessories will void your warranty. This limited warranty extends only to the original purchaser and is not transferable. This warranty is valid only if the product has been registered with Challenger Lifts, Inc., www.challengerlifts.com.

This warranty does not cover normal maintenance or adjustments, damage or malfunction caused by improper handling, installation,abuse, misuse, negligence, carelessness of operation, or normal wear and tear. In addition, this warranty does not cover equipment whenrepairs have been attempted or made by anyone other than a CLI authorized service representative.

This warranty is exclusive and is in lieu of all other warranties expressed or implied including any implied warranty of fitness for a particular purpose, which implied warranties are expressly excluded. No employee, agent, representative, dealer or other person or entity isauthorized to give any warranties of any nature on behalf of CLI.

The remedies described are exclusive and in no event shall CLI, Inc. be liable for special, consequential or incidental damages for the breach of or delay in performance of the warranty. This warranty shall be governed by the Commonwealth of Kentucky, and shall be subject to the exclusive jurisdiction of the Court in the Commonwealth of Kentucky in the County of Jefferson.

Functional parts are considered the power units, cylinders, sheaves, sheave pins, hoses, hydraulic & pneumatic fittings, cables, adapters, latches, valves, and controls.

Structural parts are considered the carriage, columns, column extensions, overhead beams, arms, cross beams, runways, wheel stops, ramps, bolsters, sync rails, and plungers.

Note: Warranty registration must be completed online at https://www.challengerlifts.com/register-your-lift/ or warranty period will beging from invoice date of lift purchase.
